Display | |
Size | 28” |
Resolution | 3840×2160 |
Brightness | 300cd/m² |
Aspect ratio | 16:9 |
Contrast | 1000:1 |
Viewing Angle | 170°/160°(H/V) |
Video Input | |
SDI | 2×12G, 2×3G (Supported 4K-SDI Formats Single/Dual/Quad Link) |
HDMI | 1×HDMI 2.0, 3xHDMI 1.4 |
Video Loop Output (Uncompressed true 10-bit or 8-bit 422) | |
SDI | 2×12G, 2×3G (Supported 4K-SDI Formats Single/Dual/Quad Link) |
Supported In / Out Formats | |
SDI | 720p 50/60, 1080i 50/60, 1080pSF 24/25/30, 1080p 24/25/30/50/60, 2160p 24/25/30/50/60 |
HDMI | 720p 50/60, 1080i 50/60, 1080p 24/25/30/50/60, 2160p 24/25/30/50/60 |
Audio In/Out (48kHz PCM Audio) | |
SDI | 12ch 48kHz 24-bit |
HDMI | 2ch 24-bit |
Ear Jack | 3.5mm |
Built-in Speakers | 2 |
Power | |
Operating power | ≤61.5W |
DC In | DC 12-24V |
Compatible batteries | V-Lock or Anton Bauer Mount |
Input voltage (battery) | 14.4V nominal |
Environment | |
Operating Temperature | 0℃~50℃ |
Storage Temperature | -20℃~60℃ |
Other | |
Dimension(LWD) | 670×425×45mm / 761×474×173mm (with case) |
Weight | 9.4kg / 21kg (with case) |
Display | |
Size | 28” |
Resolution | 3840×2160 |
Brightness | 300cd/m² |
Aspect ratio | 16:9 |
Contrast | 1000:1 |
Viewing Angle | 170°/160°(H/V) |
Video Input | |
SDI | 2×12G, 2×3G (Supported 4K-SDI Formats Single/Dual/Quad Link) |
HDMI | 1×HDMI 2.0, 3xHDMI 1.4 |
Video Loop Output (Uncompressed true 10-bit or 8-bit 422) | |
SDI | 2×12G, 2×3G (Supported 4K-SDI Formats Single/Dual/Quad Link) |
Supported In / Out Formats | |
SDI | 720p 50/60, 1080i 50/60, 1080pSF 24/25/30, 1080p 24/25/30/50/60, 2160p 24/25/30/50/60 |
HDMI | 720p 50/60, 1080i 50/60, 1080p 24/25/30/50/60, 2160p 24/25/30/50/60 |
Audio In/Out (48kHz PCM Audio) | |
SDI | 12ch 48kHz 24-bit |
HDMI | 2ch 24-bit |
Ear Jack | 3.5mm |
Built-in Speakers | 2 |
Power | |
Operating power | ≤61.5W |
DC In | DC 12-24V |
Compatible batteries | V-Lock or Anton Bauer Mount |
Input voltage (battery) | 14.4V nominal |
Environment | |
Operating Temperature | 0℃~50℃ |
Storage Temperature | -20℃~60℃ |
Other | |
Dimension(LWD) | 670×425×45mm / 761×474×173mm (with case) |
Weight | 9.4kg / 21kg (with case) |
